Solite is a high-performance patterned glass designed to enhance solar energy absorption. Its unique texture maximizes light transmission, making it an essential component for photovoltaic modules and solar collectors.

made in the

USA

Downloads

High-Performance Extra Clear Patterned Glass

Solite is an extra-clear patterned glass designed to enhance solar energy absorption. Its pyramidal texture on one side and smooth surface on the other optimize light transmission while reducing reflection losses. This design improves energy efficiency in photovoltaic and solar thermal systems, ensuring seamless integration and long-term durability.

Designed for performance

Key Features

Designed for superior solar performance, Solite enhances energy absorption while maintaining durability and optical clarity, making it a reliable choice for renewable energy applications.

  • Optimized Solar Transmission - Maximizes energy transfer across the solar spectrum
  • Durable & Tempered – Fully tempered according to ANSI Z97.1 for enhanced strength and safety.
  • Seamless Lamination – The patterned surface enhances adhesion in solar module assembly.
  • Glare Reduction – Pyramidal texture minimizes reflection while maintaining high light transmission.
  • ASTM C1036 Compliant – Meets industry standards for quality and performance.
  • Customizable Sizing – Available in various dimensions to meet specific project requirements.
Engineered for excellence

Technical Specifications

Solite is crafted to meet the rigorous demands of modern solar technology, offering a balance of strength, clarity, and efficiency. Its specialized composition ensures high-performance transmission while withstanding environmental stressors.

The following specifications highlight the precision and reliability that make Solite an essential choice for solar applications.

Solite Typical Values

Glass Thickness (mm)
2.0
2.5
2.7
3.0
3.2
4.0
% visible transmission
91.8
91.8
91.7
91.7
91.6
91.5
kg/m²
5.0
6.3
6.8
7.5
8.0
10.0
m²/metric tonne
200.0
160.0
148.1
133.3
125.0
100.0
lb/ft²
1.02
1.28
1.38
1.54
1.64
2.05
ft²/short ton
1954
1563
1447
1302
1221
977

Solite Typical Values

Glass Thickness (mm)
2.0
3.0
4.0
% visible transmission
91.8
91.7
91.5
kg/m²
5.0
7.5
10.0
m²/metric tonne
200.0
133.3
100.0
lb/ft²
1.02
1.54
2.05
ft²/short ton
1954
1302
977
